HSW

Style’s Horizontal Sliding Wall, known as HSW, is a multi-functional frameless glass partition system designed to provide flexibility, a feeling of openness and wellbeing with transparent sightlines. The glazed panels can be moved manually or automatically at the touch of a button.

downward arrow


Versatile glazed frameless moveable partition wall system, effortless to use, with extensive options and stacking configurations.

Including a fully automatic opening and closing option (*ComfortDrive), this solution has been tested to the most rigorous standards and meets the requirements of the most demanding venues.

HSW’s safe, fast, innovative and secure design including locking solutions, makes this system suitable for almost any setting including shop frontages, banks, offices, restaurants, offices, reception areas, hotels, residential homes, winter gardens, airports and sports stadia and arenas.


Key Features and Benefits:

  • Effortless manual operation

  • Safe & easy to use with integrated functional interlocking

  • Up to 19mm thick glass

  • Numerous stacking options available including custom configurations

  • Near silent aluminium track systems engineered with precision

  • Customisable finishes including Crittall effect and transom bars

  • Curved layouts

Technical
Specifications

The tables below outline the key technical specifications for the HSW range of sliding walls. To learn more about the Stylefold folding wall options or to discuss the best solution for your space, don’t hesitate to contact our team.

Glass Thickness (TSG*): 10mm-19mm
Frame Profiles:  Aluminium profiles. RAL colour options available
Panel Widths: 800mm-1250mm
Max Height: 4000mm
dB Ratings:  Non-Acoustic
Panel Weight: 150kg maximum
Track Construction: 72mmx 75mm Aluminium RAL9010 White
Wind Pressure Testing: In accordance with EN 1029/12207/12211/12210
Impact Load Testing: In accordance with EN 13049
Access Doors: Sliding and fixed single/double pass doors
Seals: Brush seals top and bottom. Retrofittable vertical seal option available
Ironmongery: A variety of pull handles, top & bottom locks, doorknobs and grips
Optional Frame HSW-R:  A sturdy all round bonded aluminium frame

 *Laminated Safety Glass also available

Product
Demonstration

Watch the video below to see how a fully automated glass partition wall system looks and performs in a real space. See how fast and simple it is to divide a space and gain important privacy whilst maintaining the light, spacious feel of an open plan office.
