Dorma Hüppe′s new generation of moveable walls – exclusively from Style Partitions



Dorma Variflex 88

The DORMA Hüppe development team took on the significant challenge of achieving better sound insulation with a lighter, thinner partition wall – and solved the problem to impressive effect with the Variflex 88 which is currently available up to 4100mm high.

The newly developed design exhibits a high degree of imperviousness, complemented by optimized profiles and sealing strips to produce outstanding sound reduction values of up to Rw 58dB with a wall thickness of 88mm, the weight per unit area is also significantly reduced, bringing both structural and handling benefits.

The advantages at a glance;

  • Improved sound insulation with a reduced wall thickness.
  • Space savings in the parking area.
  • Low specific weights with obvious structural advantages.
  • Easy handling

Dorma Moveo

Dorma Hüppe′s Moveo® is the new generation of moveable walls which incorporates ComforTronic® automatic seals as standard. These operable walls allow quicker operation ensuring the acoustic integrity every time.

The lightweight design makes even large moving wall panels effortless to manoeuvre and reduces structural support requirements. As well as offering very effective smoke control, the latest European standards are met with up to Rw55dB sound reduction.

A Moveo® panel weighs up to 50% less than a conventional acoustic moveable wall and is available with single point suspension up to 3 metres high and up to 9 metres with double point suspension.

Almost any finish is possible including laminate and polished wood veneers. Additional features include acoustic sound absorption boards, magnetic display boards, dry wipe marker, and projection surfaces.

Where access is required through the moveable wall we are able to offer a full height end hinged panel, a single inset pass door or a double inset pass door. The design of the pass doors ensures the overall acoustic performance of the partition is retained.

Moveo® Glass combines with standard panels to bring daylight into partitioned rooms whilst maintaining a high acoustic performance, up to Rw 50dB. When privacy is required automatic blinds can be operated by remote control.

Environmental product declaration (EPD) in accordance with ISO 14025 and EN 15804

Dorma Variflex

Dorma Hüppe′s Variflex product range includes acoustic moveable walls up to 14.5m high. These conventional manual seal moving walls offer sound reductions up to Rw 60 dB and a 30 minute fire rating.

The panels are manufactured separately to the frame, which means Dorma Variflex has interchangeable panels which are easy to change if one is damaged or scuffed, or the interior design of a room changes later on.

The Variflex system provides you with a wide choice of elements and stacking/parking arrangements.

Its high level of flexibility, even in the case of complicated room proportions where sloping ceilings or circular spaces have to be accommodated, ensures that you have all the benefits of optimum functionality.

With several extensive collections to choose from, there are no limits to the individual surface finishes that you can incorporate.

From genuine wood veneers to decor surfaces and even rugged functional finishes, we can offer you a wide range of high-quality solutions to meet in full even the highest expectations.

Environmental product declaration (EPD) in accordance with ISO 14025 and EN 15804


folding walls 1

Panels small or large can be manoeuvred to stack compactly within a room at either the end of the track or remotely within a storage recess.

folding walls 2

Operation and usage are essential and our products will satisfy customers for years offering continuous performance..

folding walls 3

Lecture theatres, particularly within schools, utilise our range of partitions offering separation of space as well as an acoustic divide to meet BB93 requirements.


Technical specification

 Dorma
Variflex
88
Dorma
Variflex
88
Dorma
Variflex
88
Dorma
Variflex
88
Dorma
Variflex
88
Rw dB Rating 41 46 53 56 58
Panel Thickness (mm) 88 88 88 88 88
Max height (mm) 4,100 4,100 4,100 4,100 4,100
Max Length (mm) Unlimited Unlimited Unlimited Unlimited Unlimited
Weight (kg/m2) 23 24 32 41 49
Available finishes Various Various Various Various Various
Panel widths (mm) 700–1,250 700–1,250 700–1,250 700–1,250 700–1,250
Minimum Void
Depth (mm)
150 (Man) / 300
(Fully Auto)
150 (Man) / 300
(Fully Auto)
150 (Man) / 300
(Fully Auto)
150 (Man) / 300
(Fully Auto)
150 (Man) / 300
(Fully Auto)
 Dorma
Moveo
Dorma
Moveo
Dorma
Moveo
Dorma Moveo
Glass
Dorma Moveo
Glass
Rw dB Rating 42 49 55 44 50
Panel Thickness (mm) 100 100 100 100 100
Max Height (mm) 6,500 6,500 6,500 4000 4000
Max Length (mm) Unlimited Unlimited Unlimited Unlimited Unlimited
Weight (kg/m2) 20* 30* 40* 34 49
Available Finishes Various Various Various Manifestations & Paint Manifestations & Paint
Panel Widths (mm) 700–1,250 700–1,250 700–1,250 700–1,250 700–1,250
Minimum Void
Depth (mm)
150 (Man) / 300
(Fully Auto)
150 (Man) / 300
(Fully Auto)
150 (Man) / 300
(Fully Auto)
150 (Man) / 300
(Fully Auto)
150 (Man) / 300
(Fully Auto)
 Dorma VariflexDorma VariflexDorma VariflexDorma VariflexDorma VariflexDorma Variflex
Rw dB Rating 38 52 55 57 58 60
Panel Thickness (mm) 100 100 100 100 120 120
Max height (mm) 14,500 14,500 14,500 14,500 14,500 14,500
Max Length (mm) Unlimited Unlimited Unlimited Unlimited Unlimited Unlimited
Weight (kg/m2) 38* 52* 52* 59* 54* 61*
Available finishes Various Various Various Various Various Various
Panel widths (mm) 700–1,250 700–1,250 700–1,250 700–1,250 700–1,250 700–1,250
Minimum Void
Depth (mm)
150 (Man) / 300
(Fully Auto)
150 (Man) / 300
(Fully Auto)
150 (Man) / 300
(Fully Auto)
150 (Man) / 300
(Fully Auto)
150 (Man) / 300
(Fully Auto)
150 (Man) / 300
(Fully Auto)

* +12.5 Kg/panel over 4,500mm high


Product Demonstration


Finishes

Classic Collection - Standard & High Pressure Laminates

  • Polar White
  • superWhite
  • White
  • Pearl Grey I
  • Pearl Grey II
  • Pearl Grey III
  • alu light
  • Cream I
  • Beige
  • Magnolia
  • cappLightBrown
  • Taupe
  • black
  • Bordeaux
  • Royal Blue
  • planked beach2
  • maple3
  • birch.jpg
  • dark cherry
  • wenge3
  • oal odessa white
  • walnut light
  • Walnut American
  • olive tree
  • Antique Oak
  • Polar White

    Polar White

  • superWhite

    Super White

  • White

    White

  • Pearl Grey I

    Pearl Grey 1

  • Pearl Grey II

    Pearl Grey 2

  • Pearl Grey III

    Pearl Grey 3

  • alu light

    Aluminium Light

  • Cream I

    Cream 1

  • Beige

    Beige

  • Magnolia

    Magnolia

  • cappLightBrown

    Cappuccino Light Brown

  • Taupe

    Taupe

  • black

    Black

  • Bordeaux

    Bordeaux

  • Royal Blue

    Royal Blue

  • planked beach2

    Planked Beech

  • maple3

    Maple

  • birch.jpg

    Birch

  • dark cherry

    Dark Cherry

  • wenge3

    Wenge

  • oal odessa white

    Oak Odessa

  • walnut light

    Walnut Light

  • Walnut American

    Walnut Dark

  • olive tree

    Olive

  • Antique Oak

    Antique Oak

Design Collection - Veneers

  • european maple
  • canadian maple
  • birch2
  • steamed beach
  • american oak
  • American ash
  • american cherry
  • european cherry
  • marcore
  • mahogany
  • american walnut
  • french walnut
  • swiss pear
  • birdseye maple
  • wenge
  • Aluminium decor
  • steel decor
  • ral
  • european maple

    European Maple

  • canadian maple

    Canadian Maple

  • birch2

    Birch

  • steamed beach

    Steamed Beach

  • american oak

    American Oak

  • American ash

    American Ash

  • american cherry

    American Cherry

  • european cherry

    European Cherry

  • marcore

    Macore

  • mahogany

    Mahogany

  • american walnut

    American Walnut

  • french walnut

    French Walnut

  • swiss pear

    Swiss Pear

  • birdseye maple

    Birdseye Maple

  • wenge

    Wenge

  • Aluminium decor

    Aluminium Decor

  • steel decor

    Steel Decor

  • ral

    Painted to RAL
